(If you want to know more about the device, click to download the User Manual)
CCTV Security Tester STest-894, with Multimeter
3.5" TFT-LCD Monitor / PTZ Controller / Video Signal Generator / DC12V1A Power Output / Audio Input Test / RS485 Data Capture / UTP Cable Tester / Multimeter
The STest-894 is developed for the On-Site installation and maintenance of video monitoring system. It can be used for displaying video, controlling PTZ, DC12V1A power for camera, Audio input test, generating images, capturing data of RS485 and testing LAN cable etc. Its functions, easy operation, and portability makes it simple for the CCTV technician to install and maintain CCTV system, improving work efficiency and get the labor cost down.
Applications:
CCTV system installation and maintenance
Dome camera and All in one camera testing
The CCTV transmitting channel testing
PTZ controller
Features:
3.5"TFT-LCD , 960(H)×240(V)resolution.
DC12V 1A power output for camera
Audio input test
PTZ control. Pan/tilts the P/T unit, zooms in/out the lens, adjusts the focus, aperture and sets and calls the preset position
Video displaying. Automatically adapts and displays the video format of NTSC/PAL.
LCD Brightness/Contrast/Color Saturation are adjustable.
Video Generating, The PAL/NTSC multi-system colorbar video generator (seven-system switchable, transmit/receive seven-system colorful imagines)
Data analyst. Captures and analyzes RS485 controlling data to help the technician to find out the problem.
Cable testing. It is powerful in testing LAN cable, measuring the connecting status ,displaying the sequence of connection and the NO. of the LAN cable.
Multi-interface and Multi-baud rate. Support RS232 ,RS485 and RS422 interface; baud rate ranging from 150, 600 to 19200bps.
Multi-protocol. Supports more than twenty PTZ protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc.
Lithium Ion Polymer Battery (3.7V DC3000mAh). The device employs advanced power control and protection circuit. The device is high power-efficient, energy saving and environmental protection. It can last 12 hours for normal use after charging for 4 hours.
Digital Multimeter performs AD/DC Voltage, AC/DC Current, Resistance, Continuity, Capacitance and Diode test, Auto / Manual Range, Data hold, Relative measuring.
Specification:
MODEL
CCTV Security TesterPRO STest-894
Video Test
Signal mode
NTSC/PAL (Auto adapt)
Display
3.5 inch digital TFT-LCD ,960 x 240 resolution
LCD adjustment
Brightness, Contrast, Saturation adjustable
Video IN/OUT
1 channel BNC Input & 1 channel Output
Video Output Mode
1.0 Vp-p
PTZ controller
Communication
RS232, RS422 simplex and RS485
PTZ Protocol
Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.
Baud Rate
150,300,600,1200,2400,4800,9600,19200bps
Video Signal Generation
Color bar generation
Output channel colorbar video signal for testing monitor or video cable
UTP CABLE TEST
UTP cable test
Test UTP cable connection status and display in the screen. Read the number of the test box.
DC12V 1A power output
DC12V power output
Output DC12V1A power for camera
Audio input test
Audio input test
test the pickup and other audio equipments on the front-end
RS485 data analyst
Data Monitor
Captures and analyzes the command data from controlling device
Digital Multimeter
Reading range
-6600~+6600
AC/DC Voltage
0-600V Auto/Manual ranging, 0.1mV resolution
AC/DC Current
6.6mA, 66mA, 660mA, 10A Manual ranging
Resistor
660, 6.6K, 66K, 660K, 6.6M, 66MΩ auto/manual range
Continuity
Built-in buzzer will sound, if resistance is lower than 50Ω
Diode
2.0V Range, 1mV resolution
Capacitor
6600pF~66,000μF auto/manual range
POWER
Power Adapter
DC5V, 2A
Battery
Built-in 3.7V Lithium polymer battery ,3000mAh
Rechargeable
After charging 3-4 hour, working time lasts 12 hours
Low Consumption
Energy saving technology
General
Working Temperature
-10℃---+50℃
Working Humidity
30%-90%
Dimension/Weight
176mmx94mmx36mm/340g
Package Includes:
1x CCTV Tester
1x Rechargable Li-ion Battery(built-in)
1x Rubber Case
1x Carrying Bag
1x LAN Cable Tester
1x BNC Cable
1x RS485 Data Cable
1x Safety Cord
1x User Manual
1x A/C Adapter(100-240V, with plug for worldwide use: US, AU, UK or Europe)
