CH-268 Top Entry CPU coin selector acceptor arcade game











We are professional manufacture of coin selector , coin acceptor , and LCD counter  company .If you demand a large quantity , please feel free to let me know .We can cooperate in B2B model.






Description



3.5” Top entry CPU equalizer with  coin reject lever.

CH-268T  TOP entry electronic coin selector.

Drop Inserting Type.

(1)Capable of accepting all size of coins &tokens.

(2)Select coin by Diameter, Thickness &Metal Content.

(3)CPU anti-string programs presetting against fraud .

(4)3 ways switch of coin triggering time duration.

(5)Adjustable VR tunning for sensitivity of coin acceptance.

(6)Inhibit Line enable accept command from Host Machine.

(7)Allow to connect to Counter(Meter).





Features

(1)CPU anti-string programs by lock operation against fraud .

(2)Prevent host machine from Slugs  Wire-stringing &Tricks.

(3)Coin drop speed & timing preset in [S]shape sliding passage CPU lock against

     unusual move ‚ abnormal stay &reverse draw 500ms ~5 seconds lock out along with

     operation auto-recovery.

(4)Compatible with wide variety of Cabinet, Door &Frame.

(5)Coin diameter double check in slot opening &lid entrance by diameter-rail

    &sampling clamp for preventing bigger invalid coin from inserting .

(6)Spring lid-wiring fully sweep sluggish coins off passage by reject lever for free from

    coin jam.

(7)More than millions times strong stroke durability of solenoid for the best

    performance of coin selecting .


 Specification:

Temperature:-15oC~+70oC

Coin Diameter:18mm~30mm

Coin Thickness:1.5mm~2.8mm

Voltage:DC+12V±10%

Quiescent Current:60mA±5%

Coin Sigal Output:O.C

Unit Ship Weight: 0.25kg




User Guide:

(1)Replace yellow plastic token to the correct coin as wish to accept in sampling clamp.

(2)Adjust diameter-rail of lid for preventing bigger invalid coins from inserting.

(3)Drive screw of lid-wing if coin thickness more than 2.5mm.

(4)Connect loom to host machine as following lines guide :

  •

  •

  •

  •

  •

  •

White line—(N.C. signal)

Green line—(N.O. signal)

Gray line—Counter (Meter)

Yellow line—inhibit/low(<+1V)

Red line—PowerDC +12V

Black Line—Ground (GND)


(5)Switch Time Duration for correct triggering of coin acceptance if necessary.

    Long duration of Pulse : 100ms

    Common duration of Pulse : 50ms

    Short duration of Pulse : 20ms

(6)VR tunning for sensitivity of coin acceptance.

    Turn clockwiste (+) for slack acceptance.

    Turn anti-clockwise(-) for tight acceptance.




Schematic:






FAQ:

<A>Insert coin but no scores:

1-Check the direction of the switch(N.O or N.C)right or not.

2-Whether the signal line had beem connected,if so,check the connection.

3-Whether there is poor contact about the socket.

4-Coin  sigal is output by open-collector,check whether the resistance (in the aimed

   board) had been connected.

5-Please check whether the coin can out smoothly.

<B>Eating the coin:

1-Adjust the coin signal speed switch.

2-please check if there is something in the coin groove made the coin pass

   unsmoothly.Then eating the coin.

3-Pls check whether the  coin can out smoothly.

<C>Unsmoothly:

1-Adjust VR knob,counterclockwise is tight, clolckwise is loose.

2-Adjust the precision switch: precise side,strict selection, the replace-coin often use

   normal side.

3-Check the sample coin whether it is in right place.

4-Change another sample coin.

5-Pls check whether the  coin can out smoothly.

<D>Coin can’t pass:

1-Whether there is poor contact about the socket.

2-Check the line and make sure it was in right connection.

3-Please check if there is something in the coin groove.

4-Check the sample coin whether it is in right place.

5-Whether the Article door solenoid had been jammed and the electromaget can’t be

   back.

6-Pls check whether the  coin can out smoothly.

<E>The forgery coin can pass:

1-Adjust the VR button,the counterclockwise side is slack ,the clockwise side is strict.

2-Push the dip switch into precise.

3-Check the sample coin whether it is in right place.

4-Whether the Article door solenoid had been jammed and the electromaget can’t be

   back.

<F>Soundless:

1-Whether there is poor contact about the socket.

2-Check the line and make sure it was in right connection.

<G>Sound several times:

1-Please check if there is something in the coin groove.

2-Whether there is poor contact about the socket.

3-ef5h4e8C8O3Me
