Eagle FishElite 500C Chartplotter / Fishfinder Combo.
External Antenna / Transom mount Transducer
The Eagle Fishelite 500C is the perfect fishfinder and chartplotter combination.
Ultra-bright, 5" (12.7 cm) diagonal screen
High-definition 320Vx240H resolution
Depth capability to 800 ft* (244 m) with 1500 watts of peak-to-peak power (187W RMS)
High-performance, low-profile 200 kHz Skimmer® transducer with built-in temp sensor delivers up to 60° of fish detection area with high sensitivity settings - Operates at boat speeds up to 70 mph (61 kts) - Variety of other transducer purchase options available
Trolling speed and distance log readings available with purchase of an optional sensor
Adjustable ping speed with automatic HyperScroll™ to display fish targets at higher boat speeds
FasTrack™ vertical bar flasher displays real-time sonar returns and relative strength of each target
Advanced Signal Processing (ASP™) automatically adjusts your settings for the best sonar picture
COLORLINE™ separates fish from nearby structure and bottom, and helps define bottom composition and hardness
Advanced Fish I.D.™ shows underwater targets in different sizes of fish symbols
FishTrack™ displays target depth readings above fish symbols
Selective on/off sonar alarms: Shallow, Deep, Fish and Zone
Waterproof card slot for one MMC/SD memory card (not included) to record sonar graphs and GPS data files, and to load high-detail electronic chart options for nav display
Compatible with optional plug-and-play Lowrance FreedomMaps™, Fishing Hot Spots® Pro, LakeMaster® Pro Maps, NauticPath™, and Navionics® electronic charts on MMC/SD cards
External 12-parallel channel GPS+WAAS reception with fast, strong satellite lock-ons, precise tracking, and position updates every second
Custom, built-in background map with enhanced continental U.S. and Hawaii detail including over 60,000 nav aids and 10,000 wrecks and obstructions in coastal and Great Lakes waters, as well as interstate exit services, and more inland navigation features
Optional GPS Mapping Accessories Pack with MapCreate™ CD software, one digital media card, and an MMC/SD card reader/writer
Saves up to 1,000 waypoints, 1,000 event markers, and 100 routes (up to 100 waypoints/route)
100 savable plot trails with up to 10,000 points per trail
42 graphic icons to mark your favorite spots
40 map zoom ranges - from 0.02 to 4,000 miles - with easy zoom-in/out control
Rugged, reliable, completely sealed and waterproof casing, even for use in harsh saltwater environments
Display Size:5 in \ 127 mm
Display Resolution:320 x 240 (H x W)
Display Type:256-color enhanced TFT LCD
Backlighting Type:Cold cathode
Resize Display Window:Yes
Sonar And GPS Overlay Data:Yes
Split Screen Presentation:Yes
SONAR / SOUNDER:
Sonar Frequency:200 kHz
Sonar Output Power:Max 1500 W
Sonar Depth:Max 800 ft \ 245 m
Ping Speed HyperScroll™:Yes
Sonar Alarms: Fish, Max and Min Depth: Yes
Speed & Distance Log: Optional
GPS / NAVIGATION:
GPS Antenna Type:External GPS+WAAS
GPS Receiver Channels:12 channels
Custom Mapping Optional:Optional MapCreate™ Accessory Pack, FreedomMaps™, and Navionics® Gold, Classic and HotMaps™
Man Overboard Feature:Yes
GPS Alarms: Yes
TECHNICAL / ENVIRONMENTAL:
Built-in Backup Memory:Yes
Casing:Sealed and waterpoof
Width:6.9 in \ 176 mm
Height: 5.4 in \ 138 mm
Depth: 3.4 in \ 86 mm
Power Supply:10 - 17 vDC
Mounting Bracket and leads
Transom mount transducer
