Details about  NEW 8CH H.264 Network Standalone Real Time CCTV DVR Mobile IE Remote View / 71KA

See original listing
NEW 8CH H.264 Network Standalone Real Time CCTV DVR Mobile IE Remote View / 71KA
Item Ended
Item condition:
Brand New
31 May, 2012 20:22:36 AEST
Winning bid:
AU $55.00
27 bids ]
AU $28.00 Standard International Flat Rate Postage | See details
Item location:
Hong Kong, Hong Kong


eBay item number:
Seller assumes all responsibility for this listing.

Item specifics

Brand New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is ... Read moreabout the condition
Product Type: Surveillance DVRs
Function: Support Remote View via Network and 3G Mobiles Number of Channels: 8

in titles & description
Product Reference: DVR7108

Please click here to see more CCTV DVR's, Cameras and other accessories

This 8-channel DVR is designed specially for security and defense field which makes this an outstanding digital surveillance product.
It has a strong network service that greatly enhances the network data transmission capacity and remote control capabilities.
It introduces an embedded LINUX operating system which offers a more stable performance.
It adopts a standard H.264 video compressed format and G.711A audio compressed format which insures high quality images and low error coding ratio.
This DVR can be completely controlled by the remote, the mouse or the buttons on the fascia, makes it a really handy and user friendly device.
This is a must have item for your new office as well as your home security add-ons.


  • H.264 main profile compression algorithm ideal for standalone DVR
  • Dual control methods: IR remote controller, USB mouse
  • Support 2 x USB 2.0 port for mouse, backup, upgrade etc...
  • USB record backup and network backup
  • Support 1 piece of SATA HDD, up to 2TB storage
  • 2 channels full D1 recording (Channels 1 & 2) + 6 channels CIF recording (Channels 3 - 8)
  • Real time single channel and multi channels playback
  • Video BNC (8ch video input, 2ch video output), Audio RCA (1ch audio input, 1ch audio output)
  • Support VGA output and TV output at the same time
  • Support Network and mobile remotely monitoring such as iPhone, Blackberry, Android, Symbian and Windows mobile
  • Smart HDDs Management: non-working HDD hibernation, HDD faulty alarm, Raid function
  • Support DHCP / PPPOE / FTP / DNS / DDNS / NTP, support WEB client, standalone client and SDK
  • With the sound system for the protection circuit, unique triple watchdog function, the unit uses very low power consumption to ensure the equipment never be hang up
  • Support more than 20 languages
  • Support Apple iPhone application "vMEye", you can this free app with your iPhone and access to view live and control live video streams from your cameras and DVRs

Capability Calculations:

The hard disk capacity formula is:
Overall Capability (M) = Channel Number x Time (in hours) x Capability in an hour (M/hour)

The recording time formula is:
Recording Time (hour) = Overall Capability (M) / [ Capability in an hour (M/hour) x Channel Number ]

For one piece of 500GB HDD, real time CIF for recording, it will keep recording for about 13 days.
HDD spaces per channel is 200M/H, if 8 channels real time CIF at 24 hours recording uninterrupted, it can last
500G / (200M/H x 24 hoursx 8 channels) = approximately 13 days

Important Notice:
This item does NOT include a hard disk.
This is to ensure that we can offer a competitive price and save the shipping cost on the item itself, please get a HDD locally.

Technical Information:

System Main Processor High performance embedded microprocessor HI3515
Operation System Embedded Linux
System Resources Multiplex operation: live, recording, playback, backup & remote access
User Interface

GUI, on-screen menu tips

Screen Display Supports 1 / 4 / 8 / 9 channels display
Menu Languages English, S-Chinese, T-Chinese, Italian, Spanish, Japanese, Russian, French, German, Portuguese, Turkish, Polish, Romanian, Hungarian, Finnish, Persian, Thai, Greek, Vietnamese, Brazilian, Hebrew, Indonesian, Arabic, Swedish, Czech, Ukrainian
Video Video Standards - PAL: 625 line, 50 fps
- NTSC: 525 line, 60 fps
Video Compression H.264 main profile
Picture resolution QCIF / CIF / HD1 / D1
Video Recording

- PAL: 704 x 576, 1 ~ 25 fps
- NTSC: 704 x 480, 1 ~ 30 fps

- PAL: 352 x 288, 1 ~ 25 fps
- NTSC: 352 x 240, 1 ~ 30 fps

Recording quality Best / Better / Good/ General / Worse / Worst
Encode capacity

- 200 / 240 fps
- Please note that ONLY Channels 1 & 2 support D1 real time recording, and Channels 3 - 8 support up to CIF

Motion Detection

- Zones: 396 (22 x 18) detection zones, Sensitivity: 1 - 6 (6 is highest)
- Trigger recording, tour, email, snapshot & FTP

Audio Audio Compression G711A
Bidrectional Talk Support
Record & Playback Recording Mode Manual > Motion Detection > Continuous
Playback Single channel and multi channels playback simultaneously, Pause, Stop, Rewind, Fast Play, Slow Play, Next file, Previous file, Repeat, Shuffle, Backup selection
Search Mode Time / Date, Motion Detection & exact search (accurate to second)
Storage & Backup

Space Occupation Audio 28.8 MB/H ; Video 25~450 MB/H
Record Storage Local hard disk and Network
Backup Mode Network download / Flash stick / Movable HDD / SATA HDD
Interface Video Input 8 channels BNC, 1.0Vp-p, 75Ω
Video Output

2 channels:
- 2 x TV BNC output , 1.0Vp-p, 75Ω
- 1 x VGA output

Audio Input 1 channel RCA
Audio Output 1 channel RCA
Net Interface RJ-45 (10M/100M)
USB Interface 2 x USB 2.0 ports
Hard Disk 1 x SATA I Type A connector (L Shape) port, Max 2TB
Environmental Power Supply AC Adaptor:
- Input: 100V - 240V, 50/60Hz, 1A
- Output: DC 12V, 3A Max
Power Consumption < 10W (not include Hard disk)
Working Temperature -0°C ~ 55°C
Working Humidity

10% ~ 90%

Atmosphere Pressure 86kpa ~ 106kpa
Dimensions approx. 300mm (W) x 240mm (D) x 48mm (H)

Weight (without hard disk)

Net weight: 1.25Kg, Gross Weight 2Kg

Package includes:
1 x 8-Channel DVR
1 x USB Mouse
1 x Remote Control
1 x Installation CD Rom
1 x User Maunal
1 x DC12V AC Adaptor (100V - 240V input)
1 x Power Cord
1 x Adaptor to suit your country (if applicable)
