Brand New sms/GPRS/ GPS Tracker TK103B vehicle Tracking system
BUY QUALITY GPS MADE BY Shenzhen Coban
PLEASE READ THE ENTIRE LISTING PRIOR TO BIDDING!!!
THE CD ON THE PICTURE IS NO MORE INCLUDED IN THE AUCTION AS THE SOFTWARE IS NOW DOWNLOADABLE IN THE MANUFACTURER'S PLATFORM WWW.GPSTRACKERXY.COM. PLEASE CONTINUE READING TO FIND OUT WHAT'S INCLUDED IN THE BOX
tHE TK103B COMES WITH A REMOTE CONTROL...
This GPS Tracker was specially made for vehicles. It's a new product based on the GSM/GPRS (850, 900, 1800, 1900MHz) network and satellite positioning system. It sets multiple functions such as real time
positioning,security, monitoring surveillance, emergency alarms and tracking in
It fully support the functions of SMS / GPRS / Internet data
transmission,to make it more widely used in large-scale monitoring, emergency
scheduling, location-based services, traffic safety and many other areas of
- vehicle Fleets
- rental vehicle
- personal vehicle
WHAT DO I NEED TO
GET IT TO WORK?
There is No subscription fees involved, No contract
All you need is an activated pre-paid GSM SIM Card from a provider such as AT&T, T-Mobile, MetroPCS or H2O, this is in case you are in the USA. But If you are located overseas, meaning in a country other than the USA, please get your SIM Card from a provider of GSM Services in your Country because this device will only work under a GSM Network. If you leave in Canada for example, use Rogers or Fido. If you are in Mexico or Latin America, use Telcel, Movistar, Claro. Please make sure you get a Standard (Mini) SIM Card, the biggest in size.
NOTE: For US users, TRACFONE, VERIZON, SPRINT, VIRGIN Mobile SIM CARDS WILL NOT WORK WITH THESE UNITS.
HOW DOES IT WORK?
The unit is powered by automotive battery, and should be installed inside a vehicle (preferably a place where it cannot be seen, for example, under the car seat). It runs on the latest GPS SiRF III chip-set, a sophisticated GPS microchip embedded into the heart of the tracker which continually reads its own location from low orbiting global satellites and then utilizes the GSM/GPRS infrastructure operated by your network provider to transmit its current location to you.
Then you can operate it on PC (Google map or software Platform) and Mobile phone. All you need to do is insert a working SIM card, it even has Quad-band Connectivity so it works anywhere in the world. The GPS Car Tracker makes no sound at all, so you are fully aware of what is happening to your car, but the inside driver and passenger don`t know that their activity and locations are been constantly reported.
TWO-WAY REAL TIME TRACKING
1. Track on PDA &Cell Phone
The SMS received from tracker including an http link, enter the link through your PDA or cell phone to get the detailed position anywhere and anytime. As pictures shown above.
Note: PDA or cell phone for this function must/support pictures viewing/and internet capability.
2. Track on Google earth
Enter the latitude and longitude on Google earth
3.Track On GPRS Monitor Software in CD to Install in Your PC: Real time track on your PC and route repeat.
4. Track on GPRS Web-server Monitor Center: Real Demo on www.gpstrackerxy.com (Test ID: demo Password:8888), supports English, Portuguese, Spanish, Thai, Simplified Chinese.
Note: This TK103B car GPS tracking device does not come with a SIM card you can buy one in the local store.
FOR ONLINE TRACKING
web-based platform www.gpstrackerxy.com ( demo ID:demo , password:8888).
To use the web-based platform www.gpstrackerxy.com , we should configure the gps device’s IP, Port, APN to connect gprs .
Step One : APN Configuration
1. APN standards for Access Point Name differs from country to country. For more information about the local APN, inquire with your local GPRS network operator.
2. Send the SMS to tracker : “APN123456 + Space +YourlocalAPN” ,if succeeded in setup, the tracker will return the message “APN OK”
e.g. send SMS command “apn123456 cmnet” to tracker device. If succeeded, “APN OK” is returned by the tracker in SMS.
Notes: 123456 refers to password of tracker and CMNET is the APN of a China Mobile Company.
Step TWO : IP Address and Port Setup
If you are using our server 1 , please send adminip123456 18.104.22.168 9000
If you are using our server 2, please send adminip123456 22.214.171.124 9000
Step THREE : Send SMS “gprs+password” to the unit, and it will reply “GPRS ok!” .
For example , send “ gprs123456 “ to tracker .
Step FOUR ( Not compulsory ) : GPRS Login User Name and Password Configuration
1. In most countries, the user name and password involving GPRS login are not compulsorily necessary. Therefore, the entry can be skipped. For those countries requiring user name and password, please configure as follows:
2. Send SMS command “up123456+Space+User+Space+Password”. If succeeded, “user, password OK” is returned by the tracker in SMS.
E.g. Send SMS “up123456 Jonnes 666666” to the tracker, and if succeeded, the tracker returns "user, password OK".
Notes: 123456 refers to password of the tracker, Jonnes user name and 666666 GPRS password.
5.7. Sign up user ID and password
Enter www.gpstrackerxy.com ,chose server1 or server 2, click register, setting up a user ID and password and save, and be sure to keep the user ID and password in mind.
Here is a small list of what it can do for you and your vehicle
1. Track on Demand - Replies with a TXT message of current latitude, longitude, speed, and time, as well as an Internet map link to your cellphone to show you exactly where the GPS tracker/your vehicle is.
2. Geo-fencing control - When the vehicle moves in/out the preset scope, it will send an SMS alarm to the authorized phone numbers.
3. Movement and Speed Alert: The tracker can warm you with SMS message when the vehicle starts to move from a stationary status, or when the vehicle is moving faster than a preset speed.
4. Stop the Engine: You can send an SMS message to the tracker to cut off the gas and battery power, so the engine will remain in an immobilized stated until your remove the alarm status.
5. GPRS: With a GPRS enabled SIM card, you can monitor real-time movement of your vehicle with the supplied software on your computer
More safety and convenience, by (running on a personal computer) remote control software can cut off the vehicle oil and the circuit also can be connections the original vehicle are vibration sensors and automotive door control switch.
It can help you track anything such as your car, boat and other vehicle in time. You will not worry about losing them forever.
It is working based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or internet. Please visit my store to buy it now.
1 x GPS unit tk103b
1 x 10-PIN Harness
1 x Relay
1 x remote Control
1 x Microphone
1 x Instructions Manual
1 x GPS Antenna 3 meters long
1 x GSM Antenna 2 meters long
