Details about  USB Dual Channel Digital Storage Oscilloscope 2CH 48M/s sampling + Data Logger

USB Dual Channel Digital Storage Oscilloscope 2CH 48M/s sampling + Data Logger

Seller information

99.6% Positive feedback
Visit store:
maxonic1990

Item Information

Item condition:
Brand New
Error icon
4 available / 5 sold
Please enter a quantity of $qty_dummy$ or less Please enter a quantity of 1 Purchases are limited to $qty_dummy$ per buyer Please enter quantity of 1 or more Please enter a lower number Choose quantity that is less than $qty_dummy1$ or equal to $qty_dummy$ You can only choose quantity that is equal to $qty_dummy$
Price:
AU $69.00

36 watchers

Free postage
30-day returns
Limited quantity remaining
Postage:
FREE Economy delivery from outside AU | See details

Item location:
HK, Hong Kong

Posts to:
Worldwide See exclusions
Delivery:
Payments:
International shipping and import charges paid to Pitney Bowes Inc. Learn More- opens in a new window or tab
Returns:
30 day money back, buyer pays return postage See details

People who viewed this item also viewedFeedback on our suggestions

eBay item number:
111273754825
Seller assumes all responsibility for this listing.

Item specifics

Condition:
Brand New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is ... Read moreabout the condition


maxonic1990

Visit my eBay store

Store Categories



USB Dual Channel Digital Storage Oscilloscope 2CH 48MS/s sampling + Data Logger





MDSO dual-channel digital oscilloscope, with "low-cost, high-performance" as the design goals. well-designed bandwidth of 20M, 48M sampling rate, 2 channels, alternating support X, Y and XY alternating pattern of two-channel virtual oscilloscope, spectrum analyzer and data recorder.













Feature:

Powerful analysis function :

  • Support any multi-screen display, Easy to Variety of analysis;
  • Support the input waveform interpolation;
  • Support the input waveform, "add", "subtraction" and "multiplication" synthesis;
  • Support the input waveform plus Rectangle, bartlett, triangular, cosine, hanning, bartlett_hanning, hamming, blackman, blackman_Harris, tukey, Nuttall, FlatTop, Bohman, Parzen, Lanczos, kaiser, gauss, dolph_chebyshev 18 kind of window;
  • Support the input waveform filtering and design filter;
  • Support the input waveform, "Lissajous", "Amplitude", "phase", "log Amplitude", "self-power spectrum", "log self-power spectrum" ,"cross-power spectrum", "log cross-power spectrum" ,"auto-correlation" and "cross-correlation "analysis;
  • Support under logarithmic coordinate system, the input waveform, "Amplitude", "phase", "log Amplitude", "self-power spectrum", "log self-power spectrum" ,"cross-power spectrum", "log cross-power spectrum" ,"auto-correlation" and "cross-correlation "analysis.



Powerful data recorder function

  • Support continuous data collection and storage, and can move, zoom, view global data, and compare multiple data collection;
  • High-speed USB2.0 for fast transfer, unlimited long the collected data, records into files for easy viewing and analysis of collected data;
  • 24M of continuous recording up to meet the capture function of the general agreement, such as SPI, IIC, UART, etc.

Feature Description:

  • Oscilloscope / spectrum analyzer:
  • Bandwidth  20M
  • Sample  48M
  • Channel  2
  • Input voltage range  [-50V,+50V](With probe X10)
  • Memory depth   1M*2
  • AD Bit 8
  • Software trigger rising, falling, rising / falling, differential, rising /  falling+differential
  • Analysis    Waveform Synthesis:  Add, subtract, multiply;
  • Filter processing: IIR filter support "Butterworth", "Chebyshev I", "Chebyshev II", "Elliptic" type of filter design; FIR filter supports arbitrary range of frequency sampling method , and Rectangle, bartlett, triangular, cosine, hanning, bartlett_hanning, hamming, blackman, blackman_Harris, tukey, Nuttall, FlatTop, Bohman, Parzen, Lanczos, kaiser, gaussand dolph_chebyshev, window method design.
  • Waveform analysis: Lissajous, "Amplitude", "phase", "log Amplitude", "self-power spectrum", "log self-power spectrum" ,"cross-power spectrum", "log cross-power spectrum" ,"auto-correlation" and "cross-correlation ".
  • Capture frame   Continuous function of captuer the frame


Note: Due to computer USB voltage differences, the oscilloscope measurement results may have some bias, needs your own manual calibration, the specific reference to the oscilloscope use.





Data recorder:

  • Sample 0.25M~24M
  • Channel 2
  • Input voltage range [-50V,+50V](With probe X10)
  • AD Bit 8
  • Data View  The stored data can be continuous, and support global, zoom and move the viewing.


Note: The specific speed recorder with computer processing speed, and if use high sampling rate, the situation may break.



Package Included:

  • 1 x MDSO Dual-Channel Digital Storage Oscilloscope Host

  • 1 x USB Cable

  • 2 x Oscilloscope probe
