Circuit Boards & Prototyping

5 x DIY Prototype PCB Board. Hole Pitch: approx. 1.0mm/0.039". Type: Single Side. Due to the difference between different monitors, the picture may not reflect the actual color of the item.

This is a 12V Conduction delay relay module - This is a brand new and high quality delay turn-on module. the use of high-performance timing CPU design. - the power indicator LED and switch trigger timing indication LEDs; - The output can be connected to AC 250V 10A DC 30V 10A load; - There is the chronopotentiometry regulation time, adjustable from0 to 10 seconds by default, or by changing the capacitanceadjustment time longer For applications of： Vehicle equipment-delay to prevent car ignition, prevention of high sudden current to burn components and devices. Specification: 1.Module based on: NE555 chip. 2.Delay modue:delay connect module 3.Input voltage: DC12V 4.Control voltage: AC 0~250V / max. 10A, DC 0~30V / max. 10A the operating voltage: 12 volts DC; (otherwise 5V optional) 5.Max.

Description: Brand New & High quality Simple to use Cable Length : 200mm AWG:26AWG JST XH 2.5-2 Pin Male Connector Plug w/. Wire x 10 pcs JST XH 2.5-2 Pin Female Connector Plug x 10 pcs NO Retail Box. Packed Safely in Bubble Bag.

Features: Metal casing for maximum heat dissipation Casing has a center mounting hole Heavy duty terminals No. of Pins: 4 No. of Phases: Single Model: KBPC 5010 Voltage rating: 1000 V Current rating: 50 A Specifications: Color:Silver and black Size:27 x 27 x 21mm Net weight:27g Package weight:37g Package included: 1* KBPC5010 Bridge Rectifier.

Allentronics can provide High Quality PCB’s at very low and competitive prices! Your PCB file must be gerber file. The Order Process Is Simple on the upload and order process! Quantity: 10 (Default).

Description: Connect 7 6pin Slimline SATA optical drive to computer via USB port for easy test and data transfer Support any Slimline SATA CD/DVD optical driveUSB 2.0 interface, support plug and play and Hot-swamping Support USB 2.0 high-speed 480Mbps and full-speed 12MbpsCompliant with serial ATA specification revision 2.0 and 1.0 One USB 2.0 type, a male and one 7 6pin SATA female connectors availablePower and access LED indicator availableUSB bus power mode, no external power requiredNo driver required for any OSSmall size, light weight, very convenient to carry, easy to install Color: Black Length Approx.: 34 cm / 13.4 inch Operating System: Win 98/Me/2000/XP/Win 7 Package include: 1 x SATA Laptop CD/DVD Rom Optical Drive Adapter Cable.

Features: 100% Brand New and Durable Cable. 22Pin SATA is (7pin 15Pin). Power eSATA (eSATA USB combo) to 22 Pin SATA cable. Power Over eSATA connector. Your desktop will have to support the Power eSATA 5V and 12V. The Cable supports 5V/12V Power Over eSATA to SATA 22 Pin HDD Adapter Cable. It supports with 2.5", 3.5" SATA HDD and 5.25" Blueray Play, DVD Play and CD Rom with data transfer and power for 5V and 12V. Because of using 5V/12V Power Over eSATA connector. Cable length: 52cm/20.5inch Color: Black Note: Our cable support both 5V & 12V, however pls check whether your PC support 12V output. If your PC support only 5V, then you can use only with 2.5" hard driver. If your pc support output of 12V, you can use with 2.5"/3.5" and 5.25" hard driver. So if you are planing to use with.

Feature: 100% Brand new and High quality Interface: Micro HDMI male / Mini HDMI male / HDMI female Converts your HDMI Cable to any Micro HDMI or Mini HDMI Connection HD: 1440p / 1080p / 1080i / 720p / 480p Product Introduction: This 3-in-1 T Shape HDMI adapter will allow you to adapt your standard HDMI cable to either Micro HDMI or Mini HDMI. This adapters are made with premium materials and designed to last. With superior quality and construction, this is a fantastic value product. Specification: Connector 1: Micro HDMI male connector Connector 2: Mini HDMI male connector Connector 3: Standard HDMI female connector Material: Metal/Plastic Color: Black Package Content: 1X 3 in 1 HDMI Female to Mini HDMI Male Micro HDMI Male Adapter Connector.

Feature: This is a 12V Conduction delay relay module - This is a brand new and high quality delay turn-on / Turn off module. the use of high-performance timing CPU design. - the power indicator LED and switch trigger timing indication LEDs; - The output can be connected to AC 250V 10A or DC 30V 10A load; - There is the chronopotentiometry regulation time, adjustable from 0 to 60 seconds by default, or by changing the capacitance adjustment time longer Standby current: 5mA Action: 45mA For applications of： Vehicle equipment-delay to prevent car ignition, prevention of high sudden current to burn components and devices. Parameter: 1.Module based on: NE555 chip. 2.Delay module: delay connect module.

Features onboard two the L9110S motor control chip the module can simultaneously drive two DC motors or a 4-wire 2-phase stepper motor the module input voltage :2.5-12V the 800mA continuous current output capability per channel 1. Low static work current 2. Power supply voltage: DC2.5-12V 3. Each channel has 800mA continuous current output 4. Low saturation pressure drop 5. TTL/CMOS output level compatible, can be connected directly to the CPU 6. Output built-in clamping diode, apply to the perceptual load 7. Control and drive integrate in IC 8. Have pin high pressure protection function 9. Working temperature: 0-80 ℃ 10.Size:29.2(mm)x23(mm) 51 test code: #include sbit MOTOR_A_1 = P0 ^ 0; sbit MOTOR_A_2 = P0 ^ 1; sbit MOTOR_B_1 = P0 ^ 2; sbit MOTOR_B_2 = P0 ^ 3 .

Package Included: 1. 4pcs x Long female pins 2. 4pcs x Short female pins 3. 4pcs x Normal pins 4. 2pcs x ProtoBoard Shield.

Features: the main chip: ISD1820 size: 38mm * 42.5mm the working voltage: DC 3 ~ 5V Loudspeaker: 8Ω, 0.5W. 1.An easy to use 10 seconds of voice recording 2.high-quality, natural voice restored 3.can be used as propaganda module 4.with looping, jog playback, single-pass play function 5.available single-chip control 6.this module can directly drive a small speaker 8 ohm 0.5W Power supply :3-5V, which can be accessed pin power; Audio recording control mode: the key to control or microcontroller, IO has drawn the line of control; Buttons control audio recording method of operation: REC button: record button, you can press and hold the recording, release the button to stop recording; RLAYE key: trigger mode playback, press will play this whole speech; PLAYL key: jog mode playback, press and.

Description: 100% brand new and high quality Material: Electrical components Color: See pictures Item Description: 12V 100A 5-Prongs High-current welded connections for reliability Standard is a global manufacturer of original equipment ignition products; complete quality control is maintained through the manufacturing process from componentry to finished product High quality composite housings protect against harsh temperatures and severe under hood conditions Featuring brass or copper contacts where specified for extended wear All parts are manufactured to stringent quality requirements. Relays play a large role in the ever increasing amount of electronics in automobiles. Product Specification: Product: 12V 100A relay Feature: High-capacity, 100A switching capability, 1 form A.1form B .

Supports RS232 serial interface. USB specification 1.1 and 2.0 compliant. We specialize in electronic components. ICs, Capacitors, Diodes, Resistors, LEDs.

Description: USB to DC Convert Cable USB Input voltage: DC5V DC output voltage：DC 12V DC plug: 5.5*2.1mm Cable length: 1M Material: High quality copper wire Package included: 1* USB to DC Convert Cable 5V to 12V Voltage Step-Up Cable 5.5*2.1mm.

Solderless breadboard does not require soldering, it is reusable. 1 x Electronic Test Bread Board. 2 Distribution strip, Tie-point 100.

Description: 100% brand new and high quality With the development of electric technology, we have a new design of easy compact balance charger for 2 and 3 cells LiPo battery fast charging with wide AC input. A internal 100-240V AC switch power is built in, and the high precision balance circuit can supply larger current up to 850mA per cell. Double colour LED can display the process of charging (RED: charging; GREEN: full). This charger is compact and light, especially there is separated corresponding balance port for each battery pack. Specifications: Input voltage: AC 100V-240V Balance charge current: 850mA Max charger current: 3*800mA Display:3x Bicolor LED Power plug: EU Plug Display: Green & Red LED Case material: ABS Dimension: 90 x 55 x 35mm/3.5 x 2.2 x 1.4 inch Main color: Black,.

Note: the item is without the battery ! Description: we've had a lot of people looking for a dedicated and well-designed data logging shield. We worked hard to engineer an inexpensive but well-rounded design. Not only is it easy to assemble and customize, it also comes with great documentation and libraries. You can get going quickly - saving data to files on any FAT16 or FAT32 formatted SD card, to be read by any plotting, spreadsheet or analysis program. We even have a tutorial on how to use two free software programs to plot your data The included Real Time Clock timestamps all your data with the current time, so that you know precisely what happened when! SD card interface works with FAT16 or FAT32 formatted cards. 3.3v level shifter circuitry prevents damage to your SD card Real tim.

Item Description： Use for : Extensive use as electrical insulation for transformer, motor, coil, capacitor and frequency conversion power supply in electronic industry. Specifications: 100% Brand New One-side Self-adhesive Size : 10mm(width)×100ft(±5ft length) Type : Kapton Tape Heat Resistance: 280℃ Not Retail Box .Packed Safety in Bubble Bag Package Included : 1 x 10mm 100ft BGA High Temperature Heat Resistant Polyimide Gold Kapton Tape.

Features: New and high quality. Light weight and portable to carry. This battery can provide extra fly time. Perfect for Syma X5C RC copters. Specifications: Capacity: 600mAh Voltage: 3.7V Constant Discharge: 25C Charging Time: About 30 mins Cable Length: 35mm/1.38''(Approx.) Type: Lipo Battery Size: 43 x 24 x 8mm/1.69'' x 0.94'' x 0.31''(Approx.).

Description: PCB size:1.5*1.9cm work voltage:5V Output: output high level when receive laser signal; output low level when not receive laser signal. NOTE: The sensor uses a non-modulated laser receiver, please use indoors where no light, sunlight or other fixtures may interfere, recommended for use in dark environments. Package Included: 1x Laser Sensor Module.

Solderless breadboard (MB-102). Wire size: Suitabe for 29-20 AWG wires. Your support will keep us moving forward forever.

Description Electronic Parts Pack KIT for ARDUINO Component Resistors Switch Button Package Include: 30 X 100Ω Resistors 30 X 1 kΩ Resistors 30 X 4.7 kΩ Resistors 30 X 10 kΩ Resistors 30 X 47 kΩ Resistors 30 X 100 kΩ Resistors 30 X 1 MΩ Resistors 2 X 3pin 15mm B10k Rotary Potentiometer 2 X 3pin 15mm B100k Rotary Potentiometer 3 X Red 5mm LED 3 X Yellow 5mm LED 3 X Green 5mm LED 3 X White 5mm LED 3 x 4pin 12x12mm Tactile Switch 9 x 12x12mm Round Tactile Button Cap (mixed color) 6 x 12x12mm Square Tactile Button Cap (mixed color) 2 x 40pin 2.54mm single pin male.

Specifications: Quantities: A row of 40pcs Male to Female header 1P-1P Pin header Be used for 2.54mm pitch Breadboard Length: 20cm/7.87" (Approx.) This DuPont Wire/Jumper Cable is high quality, durable and reusable, a popular & best choice for construction or repair. Package Included: 1* 40PCS DuPont Wire/Jumper Cable Male to Female 1P-1P 2.54mm.

Mini toggle switch has 3-way 6-pin On / Off / On switch Perfect for music instrument wiring harness or electronic DIY project Center is a position off Dimensions (W x H) :. Approx. 1.3 x 3 cm Description: Color: silver and dark blue Diameter of mounting hole: approx. 6mm The package includes: 6 x 3-way 6-pin on-off-one mini switch Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is /- 1-3cm.

Description: The max output current 3A, long time use 2.1A, enough use. New design, 3 solid state ceramic capacitors (MCC), more safe and low ripple Synchronous rectification, High efficiency, 6.5V to 5V 0.7A can up to 97.5%, 12V to 5V 1A can up to 94%. Flat copper inductor, improve conversion efficiency With output overvoltage protection. There is 1.5A fuse, output 5V have 300W TVS tube protect your USB device Using the latest USB identification circuit, perfectly compatible with IPHONE, the most of Android phones, IPAD etc. High quality USB port, Output voltage indicator (RED) Small size, 26.4 (L) * 15 (W) * 7.4 (H) mm, Input with reverse polarity protection diode, will not damage when input connect incorrect, Ultra-low static current, 0.85 mA only. Do not need to add swith when connecte.
